Name: Pure Titanium Plate ASTM B265
SKU: N/A

Product Introduction:

The Pure Titanium Plate ASTM B265 is the most representative and widely used grade in the industrial pure titanium series (CP titanium). It strikes an ideal balance among the strength, ductility, weld-ability, and corrosion resistance, and gets the reputation as the “industrial universal titanium.” At the same time as a superior yet cost-effective choice, Grade 2 titanium plate stands as the material of choice for addressing numerous industrial corrosion and light-weighting challenges.

Pure titanium plate is a premium-grade titanium product designed to meet the demanding needs of industries like aerospace, automotive, electronics, and energy. Manufactured to ASTM B265 standards, this plate boasts exceptional strength, corrosion resistance, and high-temperature stability, making it ideal for high-stress environments.

Technical Specifications

Item	Specification
Product Name	Pure Titanium Plate ASTM B265
Standard	ASTM B265 / ASME SB265 / EN 10204 3.1
Available Grades	Gr1, Gr2, Gr3, Gr4
Thickness Range	≥ 0.2 mm
Width	Up to 1500 mm
Length	Up to 6000 mm
Density	4.51 g/cm³ (Gr1–Gr4)
Chemical Composition	According to ASTM B265; e.g., Gr2: O ≤ 0.25%, C ≤ 0.08%, Fe ≤ 0.30%, N ≤ 0.03%, H ≤ 0.015%, balance Ti
Delivery Condition	Hot Rolled (R), Cold Rolled (Y), Annealed (M)
Yield Strength	≥ 275 MPa (Gr2)
Tensile Strength	≥ 345 MPa (Gr2)
Elongation	≥ 20% (Gr2)
Young's Modulus	Approx. 104 GPa
Hardness	Approx. HRB 80 (Gr2)
Thermal Conductivity	Approx. 21.8 W/m·K (Gr2)
Coefficient of Thermal Expansion	Approx. 8.6 ×10⁻⁶ /°C (20–100°C)
Max Service Temperature	Continuous ≤ 425°C, Intermittent ≤ 540°C
Corrosion Resistance	Excellent resistance to seawater, acids, alkalis, and chlorides
Surface Finish	Pickled, Polished, Sandblasted, or Machined
NDT	Ultrasonic Testing (UT), Eddy Current Testing (ET) available upon request
Certificates	EN 10204 3.1, ASME reports, third-party inspection available
QA Items	Impurity Elements (O, N, H), Grain Size, Hardness, Ultrasonic Testing
Processing Options	Custom cutting, surface treatment, drilling, chamfering, etc.
Applications	Chemical processing, marine, heat exchangers, pressure vessels, aerospace, medical devices

Customized Dimensions and Specifications Available upon Request.

Core Advantages:

1. Exceptional Corrosion Resistance: In oxidizing, neutral media, seawater, and humid atmospheres, its surface forms a dense, robust oxide film, delivering corrosion resistance far surpassing stainless steel and rivaling platinum. It exhibits outstanding resistance to chloride ion corrosion, completely eliminating pitting and stress corrosion cracking.

2. Superior Mechanical Properties: Offers higher strength than Grade 1 while maintaining excellent ductility and toughness (good fatigue resistance), making it ideal for structural components requiring both strength and form-ability.

3. Outstanding Process-ability: Exhibits excellent cold and hot work-ability, facilitating forming operations such as stamping, bending, and flanging. Possesses exceptional weld-ability, compatible with various conventional welding techniques.

4. Lightweight and high strength: With a density of only 4.51 g/cm³ (approximately 57% that of steel), its specific strength (strength-to-density ratio) ranks among the highest in metallic materials.

5. Excellent bio-compatibility: Non-toxic with good compatibility with human tissues and blood, suitable for food processing and biomedical applications.

Core Application Fields:

1. Chemical & Petrochemical: Manufacturing heat exchangers, reactors, towers, piping, pumps, valves, etc., for handling highly corrosive media like chlorides, organic acids, and wet chlorine gas.

2. Offshore & Marine Engineering: Desalination units, ship components, submarine piping, offshore platform heat exchange systems, and specialized naval vessel parts.

3. Power Generation and Environmental Protection: Flue Gas Desulfurization (FGD) systems, nuclear power condensers, waste heat recovery units, wastewater treatment equipment.

4. Aerospace: Though not primary load-bearing structures, used for secondary load-bearing components like fire barriers, ducts, brackets, and engine-surrounding environmental parts.

5. Medical and Food Processing: Food processing equipment, brewing tanks, pharmaceutical reactors, and raw materials for medical implants.

6. Sports & Consumer Goods: High-end bicycle frames, golf club heads, premium outdoor gear, etc.

Selection Recommendations:

1. Grade 2 vs. Grade 1 (TA1): Grade 2 offers higher strength and is preferred for structural applications. Grade 1 is softer with superior ductility, suitable for deep-drawn components requiring exceptional form-ability.

2. Grade 2 vs. Grade 5 (TC4): Grade 5 (Ti-6Al-4V) is a titanium alloy with significantly higher strength than Grade 2. However, it offers slightly inferior corrosion resistance (especially stress corrosion resistance) and form-ability/weld-ability, along with higher cost. Unless extreme strength is required, Grade 2 typically provides a more economical corrosion-resistant solution.

Product Features

Exceptional Corrosion Resistance: With its natural resistance to oxidation and corrosive substances, this plate is ideal for marine and chemical environments.
Lightweight and High Strength: Provides a superior strength-to-weight ratio, making it perfect for aerospace and automotive applications.
Excellent Ductility: Allows for easy forming and shaping without cracking or breaking.
High-Temperature Stability: Performs reliably under extreme thermal conditions, ensuring durability in demanding environments.
Biocompatibility: Safe for medical and biological applications, including implants and prosthetics.
Versatile Surface Finishes: Available in polished, brushed, and acid-pickled finishes for diverse applications.
Low Thermal Expansion: Minimizes dimensional changes during temperature fluctuations, enhancing precision.
Good Electrical Conductivity: Enables its use in some electrical and electronic component applications.

Why Choose Us?

Unmatched Quality: Strict adherence to ASTM B265 standards and international certifications.
Advanced Production Capabilities: Full in-house production, from raw material melting to final processing.
Customized Solutions: Tailored to meet your specific project requirements.
Global Supply Chain: Efficient ERP-managed inventory worth $3 million USD ensures timely delivery.
Technical Support: Expert guidance for material selection and application optimization.
Research and Development: Continual investment in R&D for product innovation and improvement.
Experienced Team: Skilled professionals with decades of industry experience in titanium manufacturing.

Factory Show

Factory exterior

Factory interior

Production workshop

Raw materials

Raw material processing

Titanium sponge die casting

Production workshop

Production and processing

Detection

Main Products

Titanium Plate

Titanium Rod

Titanium Ingot

Titanium Forgings

Titanium Tube

Titanium Composite Plate

Application Areas

Power Industry

Petrochemical Industry

Machinery Manufacturing Industry

Pharmaceutical Industry

OEM Services

Shaanxi Tilong Metal Material Co., Ltd. offers comprehensive OEM services to cater to your unique requirements. From custom dimensions and finishes to specific packaging and delivery preferences, we ensure your needs are met with precision and efficiency.

Frequently Asked Questions (FAQs)

1. What are the available grades of Pure Titanium Plate ASTM B265?
We offer Gr1, Gr2, Gr3, and Gr4, each with distinct mechanical properties for various applications.

2. Can you provide custom dimensions?
Yes, our plates can be customized in thickness, width, and length to suit your specific needs.

3. Do you provide certifications?
Absolutely. We supply ISO 9001, AS9100, and PED certifications along with your order.

4. What industries can benefit from this product?
Our titanium plates are ideal for aerospace, automotive, energy, electronics, and even medical industries.

5. How do you ensure on-time delivery?
Our advanced ERP system and extensive inventory ensure timely and reliable order fulfillment.
