High Pressure Composite Vessels

Product Overview

High pressure composite vessels are advanced storage containers designed to hold gases under extremely high pressure while maintaining minimal weight and maximum structural strength. These vessels are made by combining a lightweight liner with high strength fiber reinforcements through filament winding technology.

They are widely used in hydrogen storage systems compressed natural gas vehicles self contained breathing apparatus medical gas transport and aerospace applications where safety weight and performance are critical.

Core Structure

Each high pressure composite vessel includes a gas tight liner and a continuous fiber wrap. The liner ensures internal gas containment while the composite overwrap provides structural integrity and pressure resistance. Depending on application the liner may be made of aluminum or polymer and the fiber material includes carbon fiber glass fiber or a hybrid.

We specialize in manufacturing Type III composite vessels which use an aluminum liner fully wrapped with high performance composite fibers. This structure provides the best balance between gas compatibility low weight and high pressure performance.

Technical Specifications

Product Type
High Pressure Composite Vessel Type III

Working Pressure
200 to 700 bar customizable per request

Burst Pressure
Minimum 225 percent of working pressure

Volume Range
1 to 300 liters or as specified

Liner Material
Aluminum alloy with surface treatment

Fiber Wrap
Carbon fiber glass fiber or hybrid

Operating Temperature
Minus 40 degrees Celsius to plus 85 degrees Celsius

Design Life
Up to 20000 pressure cycles or 20 years

Compliance Standards
ISO 11119 EN 12245 DOT GB 28053 and more

Testing
Each vessel is pressure tested sealed and inspected before shipment

Product Features

Lightweight construction for mobile and transport applications
High strength to weight ratio supports extreme pressure
Excellent fatigue resistance with long service life
Low gas permeability ensuring safe long term gas storage
Corrosion resistance in harsh and demanding environments
Supports hydrogen CNG oxygen and various industrial gases
Custom sizes shapes and pressure ratings available on request

Applications

Hydrogen energy vehicles and refueling stations
CNG storage systems for buses and commercial fleets
SCBA and SCUBA equipment for firefighting and rescue
Medical gas transport cylinders
High altitude UAV and aerospace energy storage
Industrial backup gas systems and portable gas supply

Manufacturing Process

Precision liner forming and inspection
Surface preparation and resin treatment
Filament winding using programmable machines
Thermal curing in temperature controlled ovens
Hydrostatic and burst pressure testing
Final quality inspection labeling and packaging

Quality Control

Produced under strict international manufacturing standards
Material traceability from raw materials to finished vessel
100 percent of units pressure tested before delivery
Batch tracking and serialized identification
Third party inspection and certification support available

Packaging and Delivery

Protective internal foam and plastic wrap
Outer packaging using wood crates or cartons
Bulk and individual shipment supported
Lead time between 7 and 15 working days
Global shipping and logistics coordination provided

Why Choose Us?

Specialized in Type III composite vessels for over 10 years
Advanced production lines with strict process control
Strong engineering team for custom projects
Reliable lead time and stable quality
OEM and ODM support for global clients

OEM and Custom Options

Custom water volume liner size and fiber material
Support for colored surface branding and logo printing
Adaptation to regional certification standards
Application oriented designs for hydrogen UAV firefighting and more

Frequently Asked Questions (FAQs)

What is the maximum pressure your vessels can support
We offer vessels rated up to 700 bar working pressure with a burst pressure exceeding safety standards

Can I request a custom shaped vessel
Yes we support custom molds and designs based on your project requirements

Which gases are compatible with your vessels
Our vessels are suitable for hydrogen natural gas oxygen nitrogen helium and similar gases
