Composite Pressure Vessel

Product Overview

Composite pressure vessels are advanced containers designed to store compressed gases under high pressure with high strength and low weight. These vessels are widely used in hydrogen energy systems, CNG vehicles, industrial gas transport, medical oxygen supply, and safety equipment.

There are four main types of composite pressure vessels based on liner material and fiber reinforcement structure

Type I
All metal structure typically made of steel
Heaviest type with the lowest weight efficiency

Type II
Metal liner partially wrapped with glass fiber composite in the hoop area
Lighter than Type I with improved strength

Type III
Metal liner fully wrapped with continuous composite fibers
Excellent strength to weight ratio and long service life
This is the type we specialize in manufacturing

Type IV
Plastic liner with full composite fiber wrap
Lightest structure used in weight sensitive applications
Lower gas barrier performance compared to Type III

Among these types Type III composite pressure vessels offer the best balance of gas compatibility structural strength and long term reliability This type has become the preferred choice for demanding energy and industrial applications

Structural Advantage of Type III

Type III vessels use a high strength aluminum liner that provides a stable gas barrier and ensures compatibility with hydrogen oxygen and CNG gases The outer body is fully overwrapped with carbon fiber glass fiber or hybrid composite through advanced filament winding This results in reduced overall weight without sacrificing pressure resistance

Key Specifications

Vessel Type
Type III Composite Pressure Vessel

Liner Material
Aluminum alloy

Fiber Reinforcement
Carbon fiber glass fiber or hybrid composite

Working Pressure
200 to 700 bar adjustable per application

Burst Pressure
At least 225 percent of working pressure

Temperature Range
Minus 40 degrees Celsius to plus 85 degrees Celsius

Water Volume
1 to 300 liters or customized

Service Life
Up to 20 years depending on use cycle

Standard Compliance
ISO 11119 DOT EN 12245 GB 28053

Testing
Each unit undergoes hydrostatic burst and sealing tests

Product Features

Weight reduction of over 50 percent compared to steel vessels
High safety margin with excellent fatigue and impact resistance
Strong sealing performance and low gas permeability
Corrosion resistant structure with extended lifetime
Stable operation in extreme temperature environments
Fully customizable in volume pressure and dimensions
Certified for global markets and high performance sectors

Application Fields

Hydrogen fuel storage and transportation
CNG vehicle systems and refueling stations
SCBA cylinders for fire rescue and industrial safety
Medical gas supply for portable oxygen systems
Aerospace and drone energy storage
Portable industrial gas backup systems

Manufacturing Process

Liner preparation and precision machining
Surface cleaning and chemical bonding treatment
Filament winding of carbon or glass fiber
Controlled thermal curing and resin solidification
Full inspection and hydrostatic pressure testing
Labeling coding and documentation for shipping

Quality Assurance

Compliance with global safety and performance standards
100 percent product testing and visual inspection
Material traceability and batch tracking
Third party certification and reporting support
Comprehensive quality documentation on delivery

Packaging and Delivery

Protective foam and shrink wrap for each cylinder
Export grade wooden box or carton packing
Flexible shipping options for air land and sea transport
Lead time normally 7 to 15 working days
Custom export labeling and markings provided

Why Choose Us?

We are a professional manufacturer of Type III composite pressure vessels
Focused on high pressure energy storage solutions since establishment
Advanced production lines for filament winding and curing
Rich experience in OEM and special project customization
Fast delivery consistent quality and responsive customer support

OEM and Custom Options

Custom working pressure and water volume
Liner alloy and fiber material can be selected
Support for branding surface color and labeling
Application specific vessel design for hydrogen UAV or firefighting use

Frequently Asked Questions (FAQs)

What makes Type III composite vessels superior
Type III offers strong gas sealing from the metal liner and high pressure resistance from the full composite wrap combining safety durability and lightweight features

Can you manufacture according to specific standards like ISO or DOT
Yes we support production under multiple international standards

What is the usual lifespan of a Type III vessel
Service life can reach up to 20 years depending on actual pressure cycles and maintenance
