Name: Composite Titanium Aluminum Plate
SKU: N/A

Composite Titanium Aluminum Plate – High-Performance Materials for Critical Applications

Product overview:

Composite Titanium Aluminum Plate is a new type of composite material achieved through advanced processes such as rolling composite and explosion composite, which realizes the metallurgical bonding of the titanium layer and the aluminum layer. It perfectly combines the corrosion resistance and wear resistance of titanium with the lightweight and easy processing advantages of aluminum. It is widely applied in various fields such as construction, industry, and electronics.

Structure and Composition of titanium-aluminium Plate:

Structural Composition: it is usually used a dual-layer composite structure of “titanium layer + aluminum layer.” The titanium layer, usually 0.2–0.5mm thick, primarily provides the corrosion resistance and reinforcement, and varying from 1.0–2.85mm in thickness, serves as the substrate ensuring lightweight properties and machinability. It can also be processed into composite structures like honeycomb panels, e.g., 30mm honeycomb panel (2.0mm titanium-aluminum sheet + 17mm honeycomb core + 1.0mm aluminum sheet).

Core Performance Advantages：

The core advantages of titanium-aluminum lies in combining titanium's corrosion resistance and toughness with aluminum's lightweight and easy-to-process characteristics. So it is wide-found in extensive applications across multiple fields including construction, industry, and transportation,etc.

1. Complementary Performance Benefits: Making full use of the advantage of the titanium layer with exceptional corrosion resistance, such as withstanding harsh environments like acids, alkalis and the aluminum layer maintains lightweight properties, reducing weight by 32% compared to pure titanium plates of identical thickness and area.

2.Outstanding Cost-Effectiveness: Compared to pure titanium plates, titanium-aluminum composite plates significantly reduce material costs. At equivalent weight and thickness, their unit price per square meter is only 48.6% of pure titanium, enabling high performance while controlling overall project budgets.

3.Outstanding Processability: Far surpassing pure titanium in malleability, it facilitates embossing, perforation, and bending. Capable of producing irregular shapes, corrugated panels, and other forms, it also accommodates large-span designs—such as single panels measuring 3m × 1.5m—reducing joint seams while enhancing construction efficiency and visual integrity.

Technical Specifications:

Property	Value
Material Composition	Titanium (Ti) and Aluminum (Al) Alloy
Thickness	1mm – 50mm (Custom thickness available)
Density	3.7 g/cm³
Tensile Strength	900-1,200 MPa
Yield Strength	800-1,100 MPa
Hardness	Brinell 250 HB
Corrosion Resistance	Excellent, especially in acidic environments
Heat Resistance	Up to 500°C
Electrical Conductivity	Moderate (for applications requiring conductivity)
Surface Finish	Polished, Sandblasted, Anodized
Custom Sizes	Available upon request

Primary Applications of Composite Titanium Aluminum Plate：

The application fields of Ti-Al composite plates revolve around their core advantages of "corrosion resistance + lightweight + easy processing", covering various core scenarios such as construction, industry, and high-end manufacturing. The details are as below:

1. Architectural decoration;

2. Industrial anti-corrosion and chemical industry: chemical equipment, ocean engineering and electrolytic industry,etc.

3. High-end manufacturing and transportation: electronic devices, aerospace and new energy vehicles,etc.

4. Other special fields: such as medical equipment and rail transportation, and so on.

Product Features

Lightweight & High Strength: By combining titanium and aluminum, our composite plates offer a high strength-to-weight ratio, making them ideal for aerospace and automotive applications.
Superior Corrosion Resistance: The titanium component ensures that the material performs exceptionally well in corrosive environments, making it perfect for marine, aerospace, and chemical industries.
Thermal Stability: These plates can withstand high temperatures, maintaining their structural integrity even in extreme conditions.
Customizable Thickness: We offer plates in a wide range of thicknesses and sizes to suit your specific needs, ensuring you get the exact material for your project.
Excellent Processing Performance: The material is easy to machine and fabricate, making it ideal for complex manufacturing processes.

Why Choose Us?

At Shaanxi Tilong Metal Material Co., Ltd., we offer more than just high-quality materials; we provide reliable, efficient, and innovative solutions tailored to your needs. Here’s why you should choose us:

Uncompromising Quality: Our Composite Titanium Aluminum Plate meets international standards and is subject to rigorous quality control processes to ensure the highest level of performance.
Customization: We understand that each industry and application is unique. That’s why we offer customizable sizes, thicknesses, and finishes to meet your specific requirements.
Experienced Team: Our team of engineers and technical experts can help you optimize your designs, ensuring you get the most out of our materials.
Fast Delivery & Reliable Supply Chain: With our advanced inventory ERP system, we can ensure timely deliveries and consistent product availability, even during high-demand periods.

Factory Show

Factory exterior

Factory interior

Production workshop

Raw materials

Raw material processing

Titanium sponge die casting

Production workshop

Production and processing

Detection

Main Products

Titanium Plate

Titanium Rod

Titanium Ingot

Titanium Forgings

Titanium Tube

Titanium Composite Plate

Application Areas

Power Industry

Petrochemical Industry

Machinery Manufacturing Industry

Pharmaceutical Industry

OEM Services

We offer OEM (Original Equipment Manufacturer) services for customers who require customized solutions. Whether you need specific dimensions, unique processing techniques, or tailored material compositions, we work closely with you to meet your exact specifications. Our team is dedicated to providing the highest level of technical support and ensuring that your manufacturing processes run smoothly.

Frequently Asked Questions (FAQs)

1. What industries can benefit from Composite Titanium Aluminum Plates?
Composite Titanium Aluminum Plates are ideal for industries such as aerospace, automotive, electronics, and energy, where high strength, corrosion resistance, and thermal stability are required.

2. Can I get a custom thickness or size for my project?
Yes, we offer customized thicknesses and sizes to meet your specific needs. Please contact us to discuss your requirements.

3. What is the maximum temperature that the Composite Titanium Aluminum Plate can withstand?
Our plates can withstand temperatures up to 500°C, making them suitable for high-temperature environments.

4. How do I place an order?
You can place an order directly through our website or by contacting our sales team for personalized service.

5. What quality certifications do you have?
Our products meet international quality standards, and we follow strict quality control procedures throughout the production process to ensure top-tier performance.
